Single size effects 092: St. Mod Delay (Stereo Modulation Delay)
267
Tap1 Level
This parameter sets the output level of Tap1. Setting a different
level from Tap2 will add a unique touch to a monotonous delay
and feedback.
092: St. Mod
Delay
(
Stereo
Modulation Delay)
This stereo delay uses an LFO to sweep the delay time. The pitch
also varies, creating a delay sound which swells and shimmers.
You can also control the delay time using a modulation source.
Dmod Modulation
When the modulation source is used for control, this parameter
reverses the left and right modulation direction.
LFO Dmod Sync
Source
L LFO Phase [deg]
R LFO Phase [deg]
If “LFO Sync” is On, the LFO will be reset by the modulation
source that is received.
The “Source” parameter sets the modulation source that resets the
LFO. For example, you can assign Gate as a modulation source so
that the sweep always starts from the specified point.
“L LFO Phase” and “R LFO Phase” set the phase obtained when
the left and right LFOs are reset. In this way, you can create
changes in pitch sweep for the left and right channels individually.
The effect is off when a value of the modulation source
specified in the “Source” parameter is 63 or smaller, and the
effect is on when the value is 64 or higher. The LFO is
triggered and reset to the “L LFO Phase” and “R LFO Phase”
settings when the value changes from 63 or smaller to 64 or
higher.
Paramter Value Explanation
L Dly[ms]
L Delay
Delay Time
[ms]
0.0...259.0
Sets the delay time
for the left channel
L Feedbck L Feedback –100...+100
Sets the feedback
amount of left delay
R Dly[ms]
R Delay
Delay Time
[ms]
0.0...259.0
Sets the delay time
for the right channel
R Feedbck R Feedback –100...+100
Sets the feedback
amount of right delay
L Depth ← 0...200
Sets the depth of the
left LFO modulation
L LFO Phase
[deg]
← –180...+180
Sets the phase
obtained when the
left LFO is reset p.268
R LFO Phase
[deg]
← –180...+180
Sets the phase
obtained when the
right LFO is reset
p.268
R Depth ← 0...200
Sets the depth of the
right LFO modulation
Mod Mode
Modulation
Mode
LFO, Dmod
Switches between
LFO modulation
control and
modulation source
control
Dmod Mod
Dmod
Modulation
L/R:+/+,
L/R:+/–
Reversed L/R control
by modulation source
p.268
Src Source Off...Tempo
Selects the
modulation source
that controls delay
time
Resp Response 0...30
Sets the rate of
response to the
modulation source
LFO
LFO
Waveform
Tri (Triangle),
Sine
Selects the LFO
Waveform
LFO Shape ← –100...+100
Changes the
curvature of the LFO
Waveform p.224
LFO [Hz]
LFO Freq
[Hz]
0.02...20.00
Sets the speed of the
LFO p.226
Sync
LFO Dmod
Sync
Off, On
Switches LFO reset
off/on
p.268
Src Source Off...Tempo
Selects the
modulation source
that resets the LFO
MIDI Sync
BPM/MIDI
Sync
Off, On
When this is on, the
LFO speed is set by
BPM, Base Note, and
Tim
es, instead of
Frequency
p.223
Left
Right
Feedback
LFO Phase
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO: Tri / Sine
Modulation Mode
D-mod
LFO
D
-mod
Delay
Delay
L/R: +/+ +/–
LFO Shape
Response
LFO Sync
BPM ←
MIDI,
40.00...
300.00
MIDI syncs to the
system tempo; 40–
300 sets the tempo
manually for this
individual effect p.223
Base Note ← ...
Selects the type of
notes that specify the
LFO speed p.223
Times ← x1...x32
Sets the number of
notes that specify the
LFO speed p.223
Wet/Dry ←
–Wet...
–1 : 99, Dry,
1 : 99...Wet
Sets the balance
between the effect
and the dry input
p.226
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
