Single size effects 074: St. Random Flanger (Stereo Random Flanger)
257
074: St. Random Flanger (Stereo
Random Flanger)
The stereo effect uses a step-shape waveform and random LFO for
modulation, creating a unique flanging effect.
075: St. Env. Flanger (Stereo
Envelope Flanger)
This Flanger uses an envelope generator for modulation. You will
obtain the same pattern of flanging each time you play. You can
also control the Flanger directly using the modulation source.
Sweep Mode
Source
This parameter switches the flanger control mode. With “Sweep
Mode” = EG, the flanger will sweep using the envelope generator.
This envelope generator is included in the envelope flanger, and
not related to the Pitch EG, Filter EG, or Amp EG.
The “Source” parameter selects the source that starts the envelope
generator. If you select, for example, Gate, the envelope generator
will start when the note-on message is received.
When “Sweep Mode” = Dmod, the modulation source can control
the flanger directly. Select the modulation source using the
“Source” parameter.
Paramter Value Explanation
LFO
LFO
Waveform
StpTri (Step-
Tri), Rndm
(Random)
Selects the LFO
Waveform p.226
LFO Phase
[deg]
← –180...+180
Sets the LFO phase
difference between
the left and right
p.226
LFO [Hz]
LFO Freq
[Hz]
0.02...20.00
Sets the speed of the
LFO p.226
Src Source Off...Tempo
Selects the
modulation source
used for both LFO
speed and step speed
Amt Amount
–20.00...
+20.00
Sets the modulation
amount of LFO speed
Step[Hz]
Step Freq
[Hz]
0.05...50.00
Sets the LFO step
speed (speed that
changes in steps)
Amt Step Amount
–50.00...
+50.00
Sets the modulation
amount of LFO step
speed
MIDI Sync
BPM/MIDI
Sync
Off, On
When this is on, the
LFO speed is set by
BPM, Base Note, and
Times, instead of
Frequency p.223
BPM ←
MIDI,
40.00...
300.00
MIDI syncs to the
system tempo; 40–
300 sets the tempo
manually for this
individual effect p.223
Base Note ← ...
Selects the type of
notes that specify the
LFO speed p.223
Times ← x1...x32
Sets the number of
notes that specify the
LFO speed p.223
Step Base
Note
← ...
Selects the type of
notes to specify the
LFO step speed p.226
Times ← x1...x32
Sets the number of
notes to specify the
LFO step speed
p.226
Depth ← 0...100
Sets the depth of LFO
modulation
Delay[ms]
Delay Time
[ms]
0.0...50.0
Sets the delay time
from the original
sound
Fe
edback ← –100...+100
Sets the feedback
amount p.257
HiDamp [%]
High Damp
[%]
0...100
Sets the feedback
damping amount in
the high range p.257
Wet/Dry ←
–Wet...
–99 : 1, Dry,
99 : 1...Wet
Sets the balance
between the effect
and the dry input
p.226, p.257
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
LFO: Step-Tri/Random
Left
Right
Feedback
LFO Phase
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
Flanger
Flanger
Paramter Value Explanation
L Btm[ms]
L Delay Time
Bottom [ms]
0.0...50.0
Sets the lower limit of
the left-channel delay
time
L Top[ms]
L Delay Time
Top [ms]
0.0...50.0
Sets the upper limit of
the left-channel delay
time
R Btm[ms]
R Delay Time
Bottom [ms]
0.0...50.0
Sets the lower limit of
the right-channel
delay time
R Top[ms]
R Delay Time
Top [ms]
0.0...50.0
Sets the upper limit of
the right-channel
delay time
Sweep Sweep Mode EG, Dmod
Determines whether
the flanger is
controlled by the
envelope generator
or by the modulation
source p.258
Src Source Off...Tempo
Selects the
modulation source
that triggers the EG
(when Sweep Mode =
EG), or the
modulation source
that causes the
flanger to sweep
(when Sweep Mode =
Dmod) p.258
EG Attack ← 1...100
Sets the EG attack
speed p.258
EG Decay ← 1...100
Sets the EG decay
speed p.258
Feedback ← –100...+100
Sets the feedback
amount
p.257
HiDamp [%]
High Damp
[%]
0...100
Sets the feedback
damping amount in
the high range
p.257
Wet/Dry ←
–Wet...
–99 : 1, Dry,
99 : 1...Wet
Sets the balance
between the effect
and the dry input
p.226, p.257
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
EG Attack/Decay
EG
D-mod
Sweep Mode
D
-mod
Flanger
Flanger
Left
Right
Feedback
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
