Effect Guide
274
102: St. BPM Mod. Delay (
Stereo BPM
Modulation Delay)
This is a stereo modulation delay that lets you synchronize the
delay time to the tempo of the song.
Time Over? L, R
You can set the delay time up to 2,550 msec. If the delay time
exceeds this limit, the error message “OVER!” appears in the
display. Set the delay time parameters so that this message will not
appear. “Time Over?” is only a display parameter.
103: St.BPMAutoPanDly (Stereo
BPM Auto Panning Delay)
This stereo auto panning delay enables you to set the delay time to
match the song tempo.
Paramter Value Explanation
ΒΠΜ
Delay BPM
MIDI,
40.00...
300.00
MIDI syncs to the
system tempo; 40–
300 sets the tempo
manually for this
individual effect p.272
T.OverL?
L Delay
Time Over?
---, OVER!
Display the error
message if the left
channel delay time
exceeds the upper
limit p.275
T.OverR?
R Delay
Time Over?
---, OVER!
Display the error
message if the right
channel delay time
exceeds the upper
limit p.275
L Dly Note Base Note ...3
Selects the type of
notes to specify the
left channel delay
time p.272
Times L Times x1...x32
Sets the number of
notes to specify the
left channel delay
time p.272
Feedbck L Feedback –100...+100
Sets the feedback
amount of left delay
R Dly Note
R Delay Base
Note
...3
Selects the type of
notes to specify the
right channel delay
time p.272
Times R Times x1...x32
Sets the number of
notes to specify the
right channel delay
time p.272
Feedbck R Feedback –100...+100
Sets the feedback
amount of right delay
L Depth ← 0...200
Sets the depth of the
left LFO modulation
LFO Phase
[deg]
← –180...+180
Sets the phase
obtained when the
left LFO is reset p.268
R Depth ← 0...200
Sets the depth of the
right LFO modulation
R LFO Phase
[deg]
← –180...+180
Sets the phase
obtained when the
right LFO is reset
p.268
Mode Mode
Modulation
Mode
LFO, Dmod
Switches between
LFO modulation
control and
modulation source
control
Dmod Mod
Dmod
Modulation
L/R:+/+,
L/R:+/–
Reversed L/R control
by modulation source
p.268
Src Source Off...Tempo
Selects the
modulation source
that controls delay
time
Resp Response 0...30
Sets the rate of
response to the
modulation source
Tempo
BPM
BPM
Base Note x Times
Base Note x Times
Left
Right
Feedback
LFO Phase
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO: Tri / Sine
Modulation Mode
D-mod
LFO
D
-mod
Delay
Delay
L/R: +/+ +/–
LFO Shape
Response
LFO Sync
LFO
LFO
Waveform
Tri (Triangle),
Sine
Selects the LFO
Waveform
LFO Shape ← –100...+100
Changes the
curvature of the LFO
Waveform p.224
LFO [Hz]
LFO Freq
[Hz]
0.02...20.00
Sets the speed of the
LFO p.226
Sync
LFO Dmod
Sync
Off, On
Switches LFO reset
off/on p.268
Src Source Off...Tempo
Selects the
modulation source
that resets the LFO
MIDI Sync
BPM/MIDI
Sync
Off, On
When this is on, the
LFO speed is set by
BPM, Base Note, and
Times, instead of
Frequency
p.223
BPM ←
MIDI,
40.00...
300.00
MIDI syncs to the
system tempo; 40–
300 sets the tempo
manually for this
individual effect p.223
Base Note ← ...3
Selects the type of
notes that specify the
LFO speed p.223
Times ← x1...x32
Sets the number of
notes that specify the
LFO speed p.223
Wet/Dry ←
–Wet...
–99 : 1, Dry,
99 : 1...Wet
Sets the balance
between the effect
and the dry input
p.226
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
Paramter Value Explanation
ΒΠΜ
Delay BPM
MIDI,
40.00...
300.00
MIDI syncs to the
system tempo; 40–
300 sets the tempo
manually for this
individual effect p.272
TimeOverL?
L Delay
Time Over?
---, OVER!
Display the error
message if the left
channel delay time
exceeds the upper
limit p.273
TimeOverR?
R Delay
Time Over?
---, OVER!
Display the error
message if the right
channel delay time
exceeds the upper
limit p.273
Tempo
BPM
BPM
Base Note x Times
Base Note x Times
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO Phase
LFO Shape
Pan
Pan
LFO: Tri / Sin
Depth
Delay
Delay
High Damp Low Damp
High Damp
Low Damp
Feedback
