Effect Guide
230
020: OD/Hi.Gain Wah (Overdrive/
Hi.Gain Wah)
This distortion effect utilizes an Overdrive mode and a Hi-Gain
mode. Controlling the wah effect, the 3-band EQ, and the amp
simulation will allow you to create versatile distortion sounds.
This effect is suitable for guitar and organ sounds.
Wah
The Wah parameter switches the wah effect on/off.
Switch Mode
This parameter sets how the wah effect is switched on and off via
the modulation source.
When “Switch Mode” = Moment, the wah effect is usually turned
off. It is turned on only when you press the pedal or use the
modulation wheel.
When a value for the modulation source is less than 64, “off”
speed is selected, and when the value is 64 or higher, “on” is
selected.
When “Switch Mode” = Toggle, the wah effect is switched
between on and off each time you press the pedal or use the
modulation wheel.
The switch will be turned on/off each time the value of the
modulation source exceeds 64.
Wah Sweep Range
Wah Sweep Src
This parameter sets the sweep range of the wah center frequency.
A negative value will reverse the direction of sweep. The wah
center frequency can be controlled by the modulation source
specified in the “Source” parameter.
Pre Low Cut
Cutting the signal in the low range before it is input to the
Distortion will create a sharp distortion.
Drive
Output Level
The degree of distortion is determined by the level of input signal
and the setting of “Drive.” Raising the “Drive” setting will cause
the entire volume level to increase. Use the “Output Level”
parameter to adjust the volume level. The “Output Level”
parameter uses the signal level input to the 3-Band EQ. If clipping
occurs at the 3-Band EQ, adjust the “Output Level” parameter.
Paramter Value Explanation
Wah ← Off, On
Switches Wah on/off
p.230
Src Source Off...Tempo
Selects the
modulation source
that switches the Wah
on and off
Sw Switch Mode
Tog gle,
Momnt
Selects the switching
mode for the
modulation source
that switches the Wah
on and off p.230
Wah Range
Wah Sweep
Range
–10...+10
Sets the range of Wah
p.230
WahSweep
Src
← Off...Tempo
Selects the
modulation source
that controls the Wah
p.230
Mode Drive Mode
Overdrive,
Hi-Gain
Switches between
overdrive and hi-gain
distortion
Drive ← 1...100
Sets the degree of
distortion p.230
Pre Low-cut ← 0...10
Sets the low range
cut amount of the
distortion input p.230
Out Level Output Level 0...50
Sets the output level
p.230
Src Source Off...Tempo
Selects the
modulation source
for the output level
Amt Amount –50...+50
Sets the modulation
amount of the output
level
Low F [Hz]
Low Cutoff
[Hz]
20...1.00k
Sets the center
frequency for Low EQ
(shelving type)
Gain [dB]
Low Gain
[dB]
–18...+18
Sets the gain of Low
EQ
Mid1 F [Hz]
Mid1Cutoff
[Hz]
300...10.00k
Sets the center
frequency for Mid/
High EQ 1 (peaking
type)
Q Mid1 Q 0.5...10.0
Sets the band width
of Mid/High EQ 1
p.221
Gain [dB]
Mid1 Gain
[dB]
–18...+18
Sets the gain of Mid/
High EQ 1
Mid2 F[Hz]
Mid2 Cutoff
[Hz]
500...20.00k
Sets the center
frequency for Mid/
High EQ 2 (peaking
type)
Q Mid2 Q 0.5...10.0
Sets the band width
of Mid/High EQ 2
p.221
Gain [dB]
Mid2 Gain
[dB]
–18...+18
Sets the gain of Mid/
Hi
gh EQ 2
Direct Mix ← 0...50
Sets the amount of
the dry sound mixed
to the distortion
SpeakerSim
Speaker
Simulation
Off, On
Switches the speaker
simulation on/off
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
l
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
+
Amp Simulation
3 Band PEQ
Output Level
Direct Mix
Pre Low-cut
D
-mod
Wah
Mode: Overdrive / Hi-Gain
Drive
Driver
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
