Single size effects 040: Stereo Auto Pan
239
LFO Freq [Hz]
Envelope Amount [Hz]
Depth
Envelope Amount Depth
The graphic below shows an example of tremolo modulation with
negative modulation of both “Depth” and “Frequency.” At the start
of the note, the input is at maximum volume. This slows down the
LFO “Frequency” to 1.0Hz, but also modulates the “Depth” to 0
so the tremolo doesn’t have any effect.
As the input volume dies down, the “Frequency” speeds up; the
“Depth” also increases, making the tremolo effect increasingly
audible. When the input volume approaches silence, the “Depth” is
at its maximum (100) and “Frequency” is at 8Hz.
040: Stereo Auto Pan
This is a stereo-in, stereo-out auto-panner. The Phase and Shape
parameters let you create various panning effects, such as making
the left and right inputs seem to chase each other around the stereo
field.
LFO Shape
You can change the panning curve by modifying the LFO’s
“Shape.”
LFO Phase [deg]
This determines the phase difference between the left and right
LFOs. When you gradually change the value away from 0, the
sounds from the left and right channels will seem to chase each
other around. If you set the parameter to +180 or –180, the sounds
from each channel will cross over each other.
You’ll only hear the effect of this parameter if the input is true
stereo, with different signals in the left and right channels.
EnvAmount
[Hz]
Envelope
Amount [Hz]
–20.00...
+20.00
Sets the amount
added to or subtracted
from the Frequency
when the envelope is
at maximum p.239
Depth
Tremolo
Depth
0...100
Sets the initial
amount of tremolo
p.239
EnvAmount-
Depth
Envelope
Amount
Depth
–100...+100
Sets the amount
added to or subtracted
from the Depth when
the envelope is at
maximum p.239
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
Level
Louder
Time
Shimmer
LFO Frequency[Hz]=8.0
Envelope Amount[Hz]= –7.0Hz
Depth=100
Envelope Amount= –100
Dry Envelope
Paramter Value Explanation
LFO
LFO
Waveform
Tri ( Triangle),
Sine
Selects the LFO
Waveform
Shape
LFO
Shape
–100...+100
Changes the
curvature of the LFO
Waveform p.239
Phase
LFO
Phase [deg]
–180...+180
Sets the LFO phase
difference between
the left and right
p.239
LFO [Hz]
LFO Freq
[Hz]
0.02...20.00
Sets the speed of the
LFO p.226
Src
LFO
Source
Off...Tempo
Selects a modulation
source for LFO speed
Amt
LFO
Amount
–20.00...
+20.00
Sets the modulation
amount of LFO speed
MIDI Sync
LFO
BPM/MIDI
Sync
Off, On
When this is on, the
LFO speed is set by
BPM, Base Note, and
Times, instead of
Frequency p.223
BPM ←
MIDI,
40.00...
300.00
MIDI syncs to the
system tempo; 40–
300 sets the tempo
manually for this
individual effect
p.223
Base Note ← ...
Selects the type of
notes that specify the
LFO speed p.223
Times ← x1...x32
Sets the number of
notes that specify the
LFO speed p.223
Depth ← 0...100
Sets the depth of LFO
modulation
Src Source Off...Tempo
Selects the
modulation source of
the depth of
modulation
Amt Amount –100...+100
Sets the modulation
amount of the depth
of modulation
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
Src Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amt Amount –100...+100
Sets the modulation
amount for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO Phase
LFO Shape
Pan
Pan
LFO: Tri / Sin
Depth
