KRONE ISOBUS Terminal
170
Pos: 48.160 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI- Rundballenpressen/ Hauptmenüs/Hauptmenü 4 Ser vice/Diagnose Versor gungsspannung @ 50\ mod_1287568818750_78. docx @ 473600 @ @ 1
Diagnostics – power supply voltage
Fig. 127
No.
Sensor icon Description
B1
U1
power supply voltage
Nominal voltages:
12V Ges: 12 - 14,5 V
12V Ter: 12 - 14,5 V
SS_5V: 4,5 - 5,5 V
8V ana: 8,5 - 9,1 V
8V dig: 8,5 - 9,1 V
12V P2: 12 - 14,5 V
Pos: 48.161 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI- BiG Pack/Hauptmenüs/ESC dr ücken um Menü Service 4 zu sc hließen bzw. zum Grundbild zu gelangen @ 44\mod_12758 93530687_78.doc x @ 393687 @ @ 1
Pressing the function key closes the called up menu
The display shows menu level 4 "Service".
Pressing the function key
and holding it down brings up the basic screen
