Comprima CV210 XC
Axle Tandem axle (axle base 1150)
Pick-up (width) 2150 mm
Permissible weights see information listed on the identification plate
Track width 2370 mm
Tyres 620/40-R 22.5
500/55-20/12 PR
Length approx. 7557 mm
Height approx. (depending on tyres) 3629 mm
Width approx. (depending on tyres) 2990 mm
Bale
dimensions
Diameter approx.
1000 mm
(Wrapping to 1750 mm diameter and a bale
weight of 1600 kg at most)
Width approx. 1200 mm
Power requirement approx. 74 kW (100 PS)
Drive speed (PTO shaft) 540 r.p.m.
Max. permissible operating pressure of
hydraulic system
min. 150 bar
max. 200 bar
Minimum oil quality Oil ISO VG 46
max. oil temperature 80°C
Delivery rate hydraulics
min. 30 l/min
max. 60 l/min
Electr.
connections
Lighting 12 volt – 7-pin plug
Operation 12 volt - 3-pin connector (DIN 9680)
Net Width max. 1300 mm
Sleeve length 1250 - 1350 mm
Sleeve diameter 75 - 80 mm
Roll diameter max. 310 mm (3000 m roll)
Sheet Width 2x750 mm (500 mm also possible)
Pre-stretch 50 % or 70 %
Sleeve diameter 75 - 80 mm
Roll diameter max. 260 mm
Overload protection system (universal shaft)
Cam-type clutch (540 r.p.m.)
2300 Nm (17 blades)
2300 Nm (26 blades)
Pos: 40.13 /BA/Einlei tung/Technische Dat en/Rundballenpres se/Technische Daten Co mprima CV 210 XC_Hydraulika nschlüsse @ 226\mod_1 392655754019_78.doc x @ 1825233 @ @ 1
Hydraulic Connections
Raising/lowering the pick-up or blade base 1 x single-action control unit
For design with hydraulic support jack 1 x double-action control unit
For design with hydraulic knife selection 1 x double-action control unit
