6. Startup
When this process has been complted without failures, the message “transmission successful“
appears.
If there is a message “transmission failed”, the data stored is probably incomplete or faulty.
Possible failure causes are:
• The transfer line between PC and SUPREMA is defective.
• The configuration database selected is faulty.
After an automatic configuration, the input of the supply voltage is missing and has to be
completed manually in the resulting listing. After transfer of this configuration database to the
SUPREMA, this failure will not occur any more.
Sending configuration data to a SUPREMA System
By clicking on the button “send to SUPREMA”, the configuration data stored in the database
selected is transferred to the SUPREMA system connected.
The transfer process has been successful if the “transmission successful“ message appears
and the SYSTEM FAIL LED at the SUPREMA has not been set.
After the transfer procedure, a new startup of the system will be necessary, otherwise, the
configuration data transferred will not work.
The configuration data transferred is checked for validity by the SUPREMA system. This validity
check has been restricted to a few basic items. It cannot check whether a configuration is
completely correct.
If the “failed in putting together the configuration data” message is shown, there is a failure in
the configuration database. In this case, no data have been transferred to the SUPREMA
system.
Possible failure causes are:
• A listing contains too little or no record at all.
• A listing contains an incomplete record.
• The database name is longer than 20 characters (not including the file extension).
If the “transmission failed” message is shown, a failure of the data transfer to the SUPREMA
system has been occurred. The configuration of the SUPREMA system is probably incomplete
and faulty.
Possible failure causes are:
• The transfer line between PC and SUPREMA system is defective.
• The SUPREMA system did not recognise the configuration data as valid.
Via the RS 232 diagnosis/service connection, failure information can be read during transfer
by a terminal program.
