REV 0, June 2005 Page 253
Operation Manual SUPREMA
12. Sensor Data Sheets
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL -LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
XXX = only alarms
XXXX = no status indication (signal change)
Open-circuit at the Wire Wire Wire Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/2 -X1/3 -X1/4 -X1/5 of MAT-(TS)
Failure indication XX X X X X X
Open-circuit at Wire Wire Wire Wire Wire Disconnect plug
max. cable length -X1/1 -X1/2 -X1/3 -X1/4 -X1/5 of MAT-(TS)
Failure indication XX X X X X X
Shor-circuit Wire Wire Wire Wire Wire Wire Wire Wire Wire Wire
at the -X1/1/ -X1/1/ -X1/1/ -X1/1/ -X1/2/ -X1/2/ -X1/2/ -X1/3/ -X1/3/ -X1/4/
MAT-(TS)-Module -X1/2 -X1/3 -X1/4 -X1/5 -X1/3 -X1/4 -X1/5 -X1/4 -X1/5 -X1/5
Failure indication X XX X X XX X X X X XX
Shor-circuit Wire Wire Wire Wire Wire Wire Wire Wire Wire Wire
at -X1/1/ -X1/1/ -X1/1/ -X1/1/ -X1/2/ -X1/2/ -X1/2/ -X1/3/ -X1/3/ -X1/4/
max. cable length -X1/2 -X1/3 -X1/4 -X1/5 -X1/3 -X1/4 -X1/5 -X1/4 -X1/5 -X1/5
Failure indication XXXX XX X X XX X X X X XXXX
Startup: Presetting required —> before first calibration and when changing sensor
Presetting: Connect digital voltmeter to MAI card jacks.
Bridge current setting —> 270 mA or 300 mA (for CH
4
)
Zero adjustment by zero gas —> Zero setting to Ua = 400 ... 450 mV
Sensitivity adjustment with measuring gas -> Measuring range level at
Ua = 1900 ... 2100 mV
or by means of the value of the existing gas concentration according to:
Ua (mV) = C (Span gas concentration in % of measuring range)/100
*
1600 + 400
Warm-up period: ≤ 120 s according to EN 50054, 15 minutes for presetting, 2 hours for calibration
Function test: Span gas application via: Integrated span gas inlet piece with 0.5 l/min,
(for standard test gases) or test cap with 1.0 l/ min, (Order No.: D6079762)
or splashwater-proof housing SG 70 with 1l/min
or pump adapter PA 70 with 1.0 l/ min
Calibration: Calibration procedure according to SUPREMA operation manual
For measuring components allowed, measuring ranges, lower alarm levels and
conditions for calibration see list of components (Order No.: D0792420)
Possible other measuring components and measuring ranges on request.
Pressure 950 ... 1100 hPa
Weight approx. 1.24 kg
Dimensions W x D x H 150 mm x 88 mm x 158 mm
Housing material Aluminum Die cast (polyester-coated)
