Operation Manual SUPREMA
12. Sensor Data Sheets
Open-circuit at the Wire Wire Wire Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/2 -X1/3 -X1/4 -X1/5 of MAT-(TS)
Failure indication XX X X X X X
Open-circuit at Wire Wire Wire Wire Wire Disconnect plug
max. cable length -X1/1 -X1/2 -X1/3 -X1/4 -X1/5 of MAT-(TS)
Failure indication XX X X X X X
Short-circuit Wire Wire Wire Wire Wire Wire Wire Wire Wire Wire
at the -X1/1/ -X1/1/ -X1/1/ -X1/1/ -X1/2/ -X1/2/ -X1/2/ -X1/3/ -X1/3/ -X1/4/
MAT-(TS)-Module -X1/2 -X1/3 -X1/4 -X1/5 -X1/3 -X1/4 -X1/5 -X1/4 -X1/5 -X1/5
Failure indication X XX X X XX X X X X XX
Short-circuit Wire Wire Wire Wire Wire Wire Wire Wire Wire Wire
at -X1/1/ -X1/1/ -X1/1/ -X1/1/ -X1/2/ -X1/2/ -X1/2/ -X1/3/ -X1/3/ -X1/4/
max. cable length -X1/2 -X1/3 -X1/4 -X1/5 -X1/3 -X1/4 -X1/5 -X1/4 -X1/5 -X1/5
Failure indication XXXX XX X X XX X X X X XXXX
Terminal box EEx e 2 x M25 x 1.5 mm KEMA 99 ATEX 3853
Dimensions W x D x H 90 x 90 x 75 mm
Weight 490 g
Temperature -20 °C ... +55 °C (T5) / -20 °C ... +40 °C (T6)
Humidity 0 ... 95 % rel. humidity; noncondensing
Pressure 100 ± 20 hPa
For further details see operation manual. (Order no.: 10052472)
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
XXX = only alarms
XXXX = no change of indication
Startup: Presetting required —> before first calibration and when changing sensor
Presetting: Connect digital voltmeter to MAI card jacks.
Bridge current setting —> 310 mA
Zero adjustment by zero gas —> Zero setting to Ua = 400 ... 450 mV
Sensitivity adjustment with measuring gas —> Measuring range level
Ua = 1950 ... 2100 mV
or by means of the value of the existing gas concentration according to:
Ua (mV) = C (Span gas concentration in % of measuring range) / 100
*
1600 + 400
Warm-up period: 15 minutes for presetting
2 hours for calibration
Function test: Span gas application via: test cap with 1.0 l/min (Order-No.: 10049316)
Calibration: Calibration procedure according to SUPREMA operation manual
For measuring components allowed, measuring ranges, lower alarm levels and
conditions for calibration see list of components. (Order-No.: D0792420)
Possible other measuring components and measuring ranges on request.
