REV 0, June 2005 Page 309
Operation Manual SUPREMA
12. Sensor Data Sheets
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
Short-circuit at Wire
max. cable length -X1/1/-X1/4
Failure indication XX
Short-circuit at the Wire
MAT-(TS)-Module -X1/1/-X1/4
Failure indication XX
Open-circuit at Wire Wire
max. cable length -X1/1 -X1/4
Failure indication X X
Open-circuit at the Wire Wire Disconnect plug
MAT-(TS)-Modulex -X1/1 -X1/4 of MAT-(TS)
Failure indication X X X
Startup: After switching on the operational voltage, the smoldering fire detector is ready for
operation after approx. 15 minutes.
Function test: Application of span gas for smoldering fire detector 0793-050
with the function tester FT-8501 0793-750
When measuring head is connected to SUPREMA, measuring head LED has no
function.
Calibration: The smoldering fire detector is supplied with smoldering fire calibration.
Calibration only at the manufacturer’s.
* With regard to fire and smoke detection, the SUPREMA has not been evaluated to any Canadian standard by
a third party agency.
