REV 0, June 2005 Page 313
Operation Manual SUPREMA
12. Sensor Data Sheets
Short-circuit at Wire
max. cable length -X1/1/-X1/2
Failure indication XX
Short-circuit at the Wire
MAT-(TS)-Module -X1/1/-X1/2
Failure indication XX
Open-circuit at Wire Wire
max. cable length -X1/1 -X1/2
Failure indication X X
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
Open-circuit at the Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/2 of MAT-(TS)
Failure indication X X X
Startup: Installation of electrochemical cells is made by user or service staff.
Installation of type A or B according to installation instructions is part of the operation
manual. (Order No.: D0765129)
After x minutes (depending from measuring cell) —> Ia = 4 mA
Function test: Application of span gas or reference gas via test cap (Order No.: D6079762)
(1 l/min)
Calibration: Depending on component (according to list of components)
Approved measuring components, calibrating conditions, measuring ranges, alarm
levels and linearisation tables see list of components: D0792420
Possible other measuring components on request.
