REV 0, June 2005 Page 321
Operation Manual SUPREMA
12. Sensor Data Sheets
Short-circuit at Wire
max. cable length -X1/1/-X1/4
Failure indication X
Short-circuit at the Wire
MAT-(TS)-Module -X1/1/-X1/4
Failure indication X
Open-circuit at Wire Wire
max. cable length -X1/1 -X1/4
Failure indication X X
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
Open-circuit at the Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/4 of MAT-(TS)
Failure indication X X X
Startup: After switching on the supply voltage, the instrument initiates a self-test.
Ia = 3 mA (adjustable); —> After approx. 5 minutes, the instrument changes over to
measuring operation. Ia = 4 mA
Explosion range: Before opening the terminal compartment, power to the measuring
head must be switched off.
Status signals: Failure —> 2 mA: Cable defect —> 0 mA
Indication at the SUPREMA display: Signal failure
Function test: Flame test
Calibration: According to operation manual.
* With regard to fire and smoke detection, the SUPREMA has not been evaluated to any Canadian standard by
a third party agency.
