REV 0, June 2005 Page 325
Operation Manual SUPREMA
12. Sensor Data Sheets
Short-circuit at Wire
max. cable length -X1/1/-X1/4
Failure indication X
Short-circuit at the Wire
MAT-(TS)-Module -X1/1/-X1/4
Failure indication X
Open-circuit at Wire Wire
max. cable length -X1/1 -X1/4
Failure indication X X
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
XXX = only alarms
Open-circuit at the Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/4 of MAT-(TS)
Failure indication X X X
Startup: After switching on the operational voltage, the measuring head is ready for operation
after approx. 5 minutes.
Warm-up period: 5 minutes for presetting, 30 minutes for calibration
Calibration/IR 3600 According to operation manual
Calibration/SUPREMA Calibration procedure according to SUPREMA operation manual
For measuring components allowed, measuring ranges, lower alarm levels see
operation manual
Possible other measuring components and measuring ranges on request.
