Operation Manual SUPREMA
12. Sensor Data Sheets
Short-circuit at Wire
max. cable length -X1/1/-X1/2
Failure indication XX
Short-circuit at the Wire
MAT-(TS)-Module -X1/1/-X1/2
Failure indication XX
Open-circuit at Wire Wire
max. cable length -X1/1 -X1/2
Failure indication X X
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
Open-circuit at the Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/2 of MAT-(TS)
Failure indication X X X
Startup: Explosion range: Before opening the terminal compartment, power to the measuring
head must be switched off.
Status signals: Calibration —> 3 mA ; Failure —> 2 mA: Cable defect —> 0 mA
Indication at the SUPREMA display: Signal failure
Function test: Test filter
Calibration: For approved measuring components, calibrating conditions, measuring ranges, alarm
levels and codes see list of components.
Possible other measuring components on request.
