REV 0, June 2005 Page 341
Operation Manual SUPREMA
12. Sensor Data Sheets
Short-circuit at Wire
max. cable length -X1/1/-X1/4
Failure indication XX
Short-circuit at the Wire
MAT-(TS)-Module -X1/1/-X1/4
Failure indication XX
Open-circuit at Wire Wire
max. cable length -X1/1 -X1/4
Failure indication X X
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
Open-circuit at the Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/4 of MAT-(TS)
Failure indication X X X
Startup: After switching on the supply voltage the UltimaX initiates a self-test. After
approximately 30 sec. the instrument changes over to measuring operation.
Warm-up periods: The warm-up periods are depending on the component and can be seen in the list
of components.
Function test: Application of span gas or reference gas via UltimaX test cap
Calibration: Dependent from component (see list of components)
For approved measuring components, calibrating conditions, measuring ranges,
alarm levels and codes see list of components.
Possible other measuring components on request.
