REV 0, June 2005 Page 343
Operation Manual SUPREMA
12. Sensor Data Sheets
Open or Short Circuit Fault Indication:
X = Signal failure (FAIL-LED)
XX = Alarm LEDs, Signal exceeded, Signal failure (FAIL-LED)
XXX = only alarms
Short-circuit at the Wire Wire Wire
MAT-(TS)-Module -X1/1/-X1/2 -X1/1/-X1/4 -X1/2/-X1/4
Failure indication XX X X
Open-circuit at Wire Wire Wire
max. cable length -X1/1 -X1/2 -X1/4
Failure indication X X X
Open-circuit at the Wire Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/2 -X1/4 of MAT-(TS)
Failure indication X X X X
Short-circuit Wire Wire Wire
max. cable length -X1/1/-X1/2 -X1/1/-X1/4 -X1/2/-X1/4
Failure indication XX XXX X
Startup: After switching on the supply voltage the UltimaX initiates a self-test. After
approximately 30 sec. the instrument changes over to measuring operation.
Warm-up periods: The warm-up periods depend on the gas.
Function test: Application of span gas or reference gas via UltimaX test cap
Calibration: Depending on gas (see list of gases)
For allowed measuring ranges, lower alarm levels and conditions for calibration
see list of gases.
Possible other gases on request.
