MSA SUPREMA - Page 61

REV 0, June 2005 Page 61
Operation Manual SUPREMA
4. Operation of the System
By selecting another interface or by pressing the [End] button and thus leaving the menu, the
inhibit of the interface is undone.
Calibration InterfaceTest Menu A
[Analog] [Serial] [Driver Output]
Interface: ---------
[Test] [End]
Test of the digital driver outputs
After a driver output has been selected by its appropriate sub system and output number, the
normal output of this driver output is inhibited. The Ï and Ð cursor keys are used to switch
between “ON” and “OFF” for changing the output value.
By pressing the [Test] button, the value set is displayed directly at the output selected. After
finishing the test press the [End] button, or by testing another driver output, the normal state of
the previous driver output is restored automatically.
Calibration InterfaceTest Menu A
[Analog] [Serial] [Driver Output]
Partial System: primary(A)
Output Number: ---
Output Value: ---
[End]
Diagnostics
Logbook
The logbook contains five histories:
• Calibration
• Events (system errors, signal problems, alarms)
• Configuration changes
• Supply Voltage
• Processor Temperature
All history entries are time-stamped. The size of the individual histories are variable. When a
history is full, the oldest entry is overwritten. One exception is the first calibration entry will not
be overwritten.
