Normally energised: When an alarm condition is exceeded (relay output is set),
a relay connected is de-energised.
Normally de-energised: When an alarm condition is exceeded (relay output is set),
a relay connected is energised.
Tag
Field type: text
Enter a customer-specific designation for the selected relay output.
New Alarm (i. e. actual alarm)
Field type: Check boxes
If this field is set, the relay output selected can be set to “normal” status by pressing the <ACKNL>
key in spite of the value having been outside the limits.
Configuration matrix
In the configuration matrices, shown as a table, it is possible to set the conditions for each
input (1
st
to 4
th
alarms, failure, inhibited) that must be met for the selected relay output to be
activated.
The following configuration conditions can be activated or deactivated by clicking with the left
mouse button in the appropriate table cell.
• Alarm Levels 1-4:
Select the alarms that will activate the selected relay, for each input. When the menu is opened,
the alarm that was selected in the input menu will be highlighted.
• Failure:
If this condition is set, the selected relay output is activated when a problem occurs for the
corresponding input.
• Inhibit:
If this condition is set, the selected relay output is activated when the corresponding input is
inhibited.
Voting (Alarm Logic)
Field type: Integer
The value entered in this field applies to the configuration conditions described above. Optio-
nal status combinations (alarm, fail, and inhibit) can be formed when the selected relay output
is configured. The number value selected in this field determines how many of the conditions
configured in the control boxes must be met for the selected relay output to be activated. The
number of conditions entered in the check boxes is displayed in the field beside the voting to
be configured.
The following types of links can be formed in this manner:
Single link: (1-out-of-1):
Exactly one condition is set, and the value of 1 is entered as the voting.
