NOTE
When the media is particularly curled, it may be somewhat difficult to slide the material under
the paper guide. In that case, you can slightly fold back the top few centimeters (no more than
10) of the media to facilitate the load process.
[122] Use both hands
9.
Press the appropriate green key inside the paper roll drawer. The material will automatically be
fed into the machine. Also refer to the sticker inside the drawer.
[123] Buttons for feeding and cutting the paper
10.
Press the green button a second time to cut off the material protruding from the paper path.
11.
Remove the scrap material.
12.
Close the roll drawer.
Load rolls of media
Chapter 8 - Maintain and troubleshoot the Océ PlotWave 750 system
305
