Page #848 background image
Operand Parameter Range Settings
[S+17] Range of link registers U0 to U128
Specify the range of link registers used for
communication (relative values within the specified
block)
[S+18]
Link relay transmission
start number
U0 to U63
Link relay sending start number (specification by
number of words, relative value within the specified
block)
[S+19]
Link relay transmission
size
U0 to U64
Size of link relay send area (specification by number
of words)
[S+20]
Link register
transmission start
number
U0 to U127
Link register sending start number (specification by
number of words, relative value within the specified
block)
[S+21]
Link register
transmission size
U0 to U127
Size of link register send area (specification by
number of words)
[S+22] Reserved area U0 -
[S+23] Reserved area U0 -
[S+24] Reserved area U0 -
[S+25] Reserved area U0 -
Content of the processing result [D]
Execution results are stored in the area of one word.
The execution result code in the low byte is valid when the process in-progress flag of bit 15
is zero.
bit no.
15 0
0 0 0 0 0 0
8 7
0: Process done
1: In-progress
Process in-progress flag
0: Normal completion
1: The communication port specified by UNITSEL instruction is invalid
2: Setting error
3: Mode change error
4: Communication port occupied
5: Change request parameter inconsistency (At the start/end of the
setting process, parameters specified by operands are inconsistent)
6: 16 or more SEND, RECV, GPTRNS, pGPSEND, and pPMSET
instructions are used simultaneously. Note 1
Execution result code
Execution result flag
0: Normal completion
1: Abnormal completion
(Note 1) Execution result code "6" is enabled for the pPMSET instruction.
Program example 1 (PMSET instruction)
This program sets 12 words of communication parameters for COM1 port of CPU with built-
in SCU, which are stored in the area starting with Data Register DT0. The processing result
is stored in DT100.
For the PMSET instruction, it is necessary to turn ON the execution condition of the PMSET
instruction until the end of processing, and turn OFF the execution condition at a scan in
which the end of data transmission is confirmed.
15.8 PMSET / pPMSET (Change of SCU Parameters)
15-54 WUME-FP7CPUPGR-12
