Panasonic FP7 Series Command Reference Manual

DT3 Transfer result
DT4-DT9
Latest transfer success
time
DT10-DT15
Latest transfer failure
time
DT16-DT17
Number of transfer
successes (Whole)
DT18-DT19
Number of transfer
failures (Whole)
DT20 LOG transfer setting Only the bit for each ID number that is set is turned ON.
DT21-DT27 Status of LOG0
The status data (7 words) for each of the 16 LOG numbers is read.
Control relay: 1 word
Execution done code: 1 word
Transfer done code: 1 word
Number of successful executions (individual): 2 words
Number of failed executions (individual): 2 words
DT28-DT34 Status of LOG 1
DT35-DT41 Status of LOG 2
- -
DT(21+7x)
-DT(27+7x)
Status of LOG x
■
Control relay
Each of the following bits is allocated for the control relay (1 word).
Bit no.
15 0
0 0 0 0 0 0 0 0
8 7
0: Transfer enabled,
1: Transfer disabled
Transfer disable relay (bit 15)
0: No request, 1: Request
Transfer request relay (bit 0)
Transfer cancel request relay (bit 14)
0: Not cancel, 1: Cancel
0: Fixed
0: Stop, 1: During transfer
Transfer active relay (bit 1)
0: No retry, 1: During retry
Retry active relay (bit 2)
0: During process, 1: Instruction execution complete
Execution done relay (bit 3)
0: Normal completion, 1: Abnormal completion
Execution result relay (bit 4)
0: Send, 1: Receive
Transfer direction relay (bit 5)
4 3
(Note 1) The transfer direction relay (bit 5) is "0" for logging or an HTTP client.
(Note 2) The transfer cancel request relay (bit 14) is "0" for logging or an HTTP client.
■
List of execution done codes
Code Name Description
0 Normal end
To be set when the processing of a transfer request instruction is
completed successfully.
1
Transfer server unset
error
To be set when the setting of the server that is accessed during the
execution of a transfer request instruction is not completed.
2
Transfer setting unset
error
To be set when the transfer setting for the transfer number that is specified
during the execution of a transfer request instruction is not completed.
3
Destination group unset
error
To be set when the destination group setting for the transfer number that is
specified during the execution of a transfer request instruction is not
completed.
4 Client registration error To be set when a process request to a client fails to register.
17.3 ETSTAT (Acquiring Ethernet Unit Information: FTP/HTTP/SMTP)
WUME-FP7CPUPGR-12 17-19
