Panasonic FP7 Series Command Reference Manual

■
Operand [S4] setting (for file transfer)
● Specify the starting address of the device area that stores the string data that indicates a
destination folder name, or a character constant.
Setting
item
Settings
S4
Destination file
name
For PUT
Specify a folder name from the home directory of a user which logs
in FTP servers with a relative path. For specifying the home
directory, specify "/" or "\" only.
Note) When an English keyboard is used, use "\" instead of "¥".
For GET
Specify a storage folder name in an SD memory card with an
absolute path.
(Note 1) When the specified destination folder does not exist, the folder is automatically created with up to eight
hierarchies.
■
Operand [S4] setting (PUT operation for a device)
● Specify the starting address of the device area that stores the string data that indicates
destination file settings, or a character constant.
Setting
item
Settings
S4
Destination file
name
Specify a destination file name.
Specify a folder name and file name with its relative path from the home directory
of the user who logs in to the FTP server.
* The string after the last "." (period) is applied as the extension of the file name.
File name
Automatic
addition
position
Specify the position of the automatic additional data added to a file name.
TOP: Automatic additional data is added before a file name.
END: Automatic additional data is added after a file name.
* Automatic additional data is year, month, day, hour, minute and second
"(yymmdd_hhmmss)".
(Note 1) Specify a destination file name within 240 characters.
(Note 2) When the specified destination folder does not exist, the folder is automatically created with up to eight
hierarchies.
(Note 3) Specify the operation setting parameters in the order of the above table.
(Note 4) When omitting "File name automatic addition position", automatic additional data is not added to the
file name.
Setting example
Exam
ple 1
S4 "\FTP\PutData1.bin,TOP"
Settings
Destination file name: \FTP\PutData1.bin
Automatic additional data: year, month, day, hour, minute and second "(yymmdd_hhmmss)"
Automatic addition position: Automatic additional data is added before the file name.
Exam
ple 2
S4 "\FTP\PutData2.bin,END"
Settings
Destination file name: \FTP\PutData2.bin
Automatic additional data: year, month, day, hour, minute and second "(yymmdd_hhmmss)"
Automatic addition position: Automatic additional data is added after the file name.
17.12 FTPcSET (FTP Client Transfer Setting)
WUME-FP7CPUPGR-12 17-67
