11A-7
TOP AND FRONT OF ENGINE
Accessories belt: Removal - Refitting
K4M, and POWER ASSISTED STEERING, and AIR CONDITIONING
11A
a Torque tighten:
-the automatic tensioning roller mounting bolts
(21 N.m),
-the fixed roller mounting bolt (21 N.m).
a Turn the accessories belt auto tensioner clockwise
using a 16 mm spanner.
a Lock the auto tensioner using a 6 mm Allen key.
a Refit a new accessories belt.
a Unlock the auto tensioner.
a Turn the crankshaft two revolutions clockwise to po-
sition the accessories belt correctly.
III - FINAL OPERATION
a Proceed in the reverse order to removal.
