82D-44
AFTER REPAIR Carry out a complete check with the diagnostic tool.
V1
MR-453-X79-82D000$170.mif
ACCESS – SAFETY
Fault finding – Fault location chart
82D
UCH
Vdiag No.: 09
ALP 10
The opening elements locking/unlocking button indicator light does
not illuminate
NOTES
Only refer to the customer complaints after performing a complete check using
the diagnostic tool.
Use the Wiring Diagrams Technical Note for DUSTER.
Set the stalk to the side lights position.
Check for the presence and condition of fuse F19 (10A) for left-hand drive, or F18 (10A) for right-hand drive on
component 1016.
Replace the fuses if the checks are not correct.
Check the condition and connection of the connectors of the central door locking switch, component code 123
and of the passenger compartment fuse box, component code 1016.
If the connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the LED status with another supply and another earth.
Check the continuity of the following connections:
• LPD between components 123 and 1016 (for a left-hand drive vehicle).
• LPG between components 123 and 1016 (for a right-hand drive vehicle).
• MAN between components 123 and earth.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, contact the Techline.
UCH_V09_ALP10
