12A-9
FUEL MIXTURE
Air filter unit: Removal - Refitting
K4M
12A
-the plastic rivets and clips every time they are re-
moved.
II - REFITTING OPERATION
a Refit:
-the air filter unit,
-the two air filter unit bolts.
a Torque tighten the air filter unit bolts (9 N.m).
a Attach the electrical wiring to the oxygen sensor.
a Refit the coolant pipes mounting bracket.
a Reclip:
-the breather,
-the coolant pipes.
a Refit:
-the filter element,
-the two air filter cover bolts.
a Reconnect:
-the brake servo vacuum pipe on the inlet distribu-
tor,
-the petrol vapour recirculation pipe,
-the throttle position potentiometer connector,
-the idle speed regulation stepping motor connec-
tor.
III - FINAL OPERATION
a Refit the air resonator (see 12A, Fuel mixture, Air
resonator: Removal - Refitting, page 12A-2) .
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
