Renault Duster 2007 - Page 82

10A-56
ENGINE AND CYLINDER BLOCK ASSEMBLY
Engine - gearbox assembly: Removal - Refitting
K4M
10A
-the cooling system (see 19A, Cooling, Cooling
system: Draining - Refilling, page 19A-6) .
a Disconnect:
-the fuel supply pipe (9) on the injector rail,
-the petrol vapour rebreather pipe (10) .
a Fit blanking plugs on the fuel supply pipe.
a Unclip the pipes at (11) .
a Disconnect the connector (12) from the fuel vapour
recirculation solenoid valve.
a Disconnect (see Power-assisted steering pump:
Removal - Refitting) (36B, Power-assisted stee-
ring):
- the power-assisted steering low pressure hose on
the power-assisted steering pump using the (Mot.
1448) and drain the circuit,
-the power-assisted steering high pressure pipe on
the power-assisted steering pump,
- the connector from the power-assisted steering
pressure switch.
145510
WARNING
To avoid any corrosion or damage, protect the
areas on which fuel is likely to run.
145509
