85A-5
WIPING - WASHING
Windscreen wiper motor: Removal - Refitting
85A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a
a Turn the wiper stalk from (0) to (1), and then from (1)
to (0).
a Remove the wiper arms (see 85A, Wiping - Wash-
ing, Windscreen wiper arm: Removal - Refitting,
page 85A-4) .
a Disconnect the battery (see 80A, Battery, Battery:
Removal - Refitting, page 80A-2) .
a Remove:
-the scuttle panel grille,
-the front windscreen wiper mechanism (see 85A,
Wiping - Washing, Windscreen wiper mecha-
nism: Removal - Refitting, page 85A-8) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove the windscreen wiper motor shaft nut (1) .
a Unclip the windscreen wiper motor connector (2) .
Tightening torquesm
windscreen wiper motor
bolts
8 N.m
windscreen wiper motor
shaft nut
16 N.m
WARNING
To ensure that the wiper arms can travel
smoothly, the wiper motor must be initialised.
LEFT-HAND DRIVE
108001
108002
