Renesas SuperH SH-4A - Page 78

Rev. 1.50, 10/04, page 58 of 448
Functional
Category
No. Instruction
Instruction
Group
Issue Rate
Execution
Cycles
Execution
Pattern
32 MOV.W R0,@(disp,Rn) LS 1 1 3-1
33 MOV.L Rm,@(disp,Rn) LS 1 1 3-1
34 MOV.B Rm,@(R0,Rn) LS 1 1 3-1
35 MOV.W Rm,@(R0,Rn) LS 1 1 3-1
36 MOV.L Rm,@(R0,Rn) LS 1 1 3-1
37 MOV.B R0,@(disp,GBR) LS 1 1 3-1
38 MOV.W R0,@(disp,GBR) LS 1 1 3-1
39 MOV.L R0,@(disp,GBR) LS 1 1 3-1
40 MOVCA.L R0,@Rn LS 1 1 3-4
41 MOVCO.L R0,@Rn CO 1 1 3-9
42 MOVLI.L @Rm,R0 CO 1 1 3-8
43 MOVUA.L @Rm,R0 LS 2 2 3-10
44 MOVUA.L @Rm+,R0 LS 2 2 3-10
45 MOVT Rn EX 1 1 2-1
46 OCBI @Rn LS 1 1 3-4
47 OCBP @Rn LS 1 1 3-4
48 OCBWB @Rn LS 1 1 3-4
49 PREF @Rn LS 1 1 3-4
50 SWAP.B Rm,Rn EX 1 1 2-1
51 SWAP.W Rm,Rn EX 1 1 2-1
Data transfer
instructions
52 XTRCT Rm,Rn EX 1 1 2-1
53 ADD Rm,Rn EX 1 1 2-1
54 ADD #imm,Rn EX 1 1 2-1
55 ADDC Rm,Rn EX 1 1 2-1
56 ADDV Rm,Rn EX 1 1 2-1
57 CMP/EQ #imm,R0 EX 1 1 2-1
58 CMP/EQ Rm,Rn EX 1 1 2-1
59 CMP/GE Rm,Rn EX 1 1 2-1
60 CMP/GT Rm,Rn EX 1 1 2-1
61 CMP/HI Rm,Rn EX 1 1 2-1
Fixed-point
arithmetic
instructions
62 CMP/HS Rm,Rn EX 1 1 2-1
