RFL Electronics Inc. June 10, 2002
RFL 9300DCDR
INPUT:
CT Input Current:
Nominal: 1 or 5 amperes
Continuous: Two-times nominal current
One-Second: Fifty-times nominal current
Frequency: 50 or 60 Hz
DTT and 89B Inputs:
93 Alarm I/O 48 V/125 Vdc (Jumper Selectable)
Input range: 38 Vdc to 58 Vdc
48 Vdc nominal at 5.5 mA
Input range: 88 Vdc to 150 Vdc
125 Vdc nominal at 3.9 mA
93 Alarm I/O 250 V:
Input range: 200 Vdc to 288 Vdc
Nominal: 250 Vdc at 12.6 mA
Burden:
1-Ampere Current Transformers: Less than 0.04W
5-Ampere Current Transformers: Less than 0.002W
OUTPUT:
Output Relays:
BREAKER TRIPPING (“TRIP”): Six sets of N.O. contacts, rated for
5 amperes continuous, 40 amperes for 0.2 seconds.
DTT OUTPUT (“DTT”): Two sets of N.O. contacts, rated for 5 am-
peres continuous, 40 amperes for 0.2 seconds.
Trip Output Seal In:
CCS or DTT Trip output contact is held closed with >200mA Trip
Current detected.
CCS Trip output contact has programmable trip release algorithms.
• Trip plus DC current sense
• Trip plus 100 ms
• Trip plus 0 ms
DTT trip output contact is released when <100mA trip current and
not trip signal present for at least 100ms.
Alarm Relays:
Communications Alarm: One set of Form C (SPDT) contacts, rated
0.1 ampere @ 125 Vdc.
System Alarm: One set of Form C (SPDT) contacts, rated 0.1 am-
pere @ 125 Vdc.
Reclose Block Output:
Optically-isolated phototransistor; operates for internal three-
phase faults.
Maximum load: 1A @ 25 deg.C @ 125 Vdc 0.675A @ 65 deg.C @
125 Vdc
Minimum load current: 0.1A
Minimum load voltage: 0.4 Vdc
GENERAL:
Sensitivity (approximate internal fault current):
1-Ampere Current Transformers: 0.2 ampere total.
5-Ampere Current Transformers: 1.0 ampere total.
Operating Times (typical):
Modem Version: 1
1/2
to 2
1/2
cycles (3 Pole only).
Direct Digital or Fiber Optic Versions: 1/2 to 1
1/2
cycles (3 Pole),
3/4 to 2 cycles (single Pole).
Direct Transfer Trip Operate Times:
Modem: <30 ms
Direct Digital: <16 ms
Modem Communications:
Modulation Scheme: CCITT V.29 QAM
Bit Rate: 7200 bps.
Input/Output Impedance: 600 (ohms).
Typical Application: May be applied to standard voice channel
(800 to 2700 Hz). Suitable for use over Type 3002 uncondi-
tioned leased lines (Class A line recommended).
Direct Digital Communications:
Interface: Complies with EIA RS-422. 56 or 64 kbps, synchro-
nous, and CCITT G.703, X.21, and V.35
Fiber Communications: See Table 1.
Diagnostic Port:
Meets the requirements of EIA Standard RS-232; equipped with
a male 9-pin D-Subminiature (DE-9P).
DNP-3.0 Protocol Interface (Optional)
MODBUS Protocol Interface (Optional)
Dielectric Withstand:
1500 Vrms for one minute, as per IEEE Std. C37.90-1989.
Surge Withstand Capability (SWC):
As per IEEE Std. C.37.90.1-1989 (reaffirmed 1991).
EMI: As per IEEE C37.90.2-1995.
Time Code Port:
Standard IRIG-B either un-modulated or 1 kHz am modulated
signal.
IRIG-B:
The display module in the RFL 9300 can be configured to accept
either of the following two types of IRIG-B signals:
1. 1 Khz modulated signal, 3.3 Vp-p for logic 1, and 1 Vp-p for
logic 0.
2. Unmodulated 0 to +5Vdc TTL signal
Resolution: 1ms
Accuracy:
Free Running: Within 1 minute per month.
Specifications
Specifications subject to change without notice.
