SEL-400 Series Relays Instruction Manual Date Code 20171006
PC Software
Create and Manage Relay Settings
Step 5. Use the following methods to edit the settings from QuickSet.
➢ Restore previous values. Right click the mouse over the setting
and select Previous Value.
➢ Restore default values. Right click in the setting dialog box and
select Default Value.
If you enter a setting that is out of range or has an error, an error
message appears at the bottom of the Settings Editor window.
To correct the error, proceed to Step 6.
Step 6. Correct settings errors.
a. Double-click on the error listing in the Settings Editor window.
b. Enter a valid input for the setting where the error appears.
Ellipsis Button
QuickSet includes a feature called an ellipsis button (see Figure 2.15).
The ellipsis button is a square button with three dots, as shown in Figure 2.16.
Use the ellipsis button to build expressions or assist with entering settings in the
relay. Whether the ellipsis button is an expression builder or a setting assistant
depends on the selected relay function and is preprogrammed in the relay. For
example, Figure 2.16 shows the ellipsis button as a setting assistant, entering
settings for the SER.
Step 1. Enter the SER settings by clicking on the Report > SER Settings in
the Tree View.
Step 2. Click on the SITM1 SER Points and Alias, Point 1 ellipsis button,
which makes the R1-SITM1 window available.
Step 3. Click on the Relay Word bit ellipsis button in the R1-SITM1 win-
dow.
The software displays a list of Relay Word bits available in the relay
that you can select to enter in the SER report.
Figure 2.15 Ellipsis Button
To Next Page
