Front-Panel Operations
Front-Panel Menus and Screens
If no SER events are available, the message shown in Figure 4.21 is displayed.
While viewing the SER events, front-panel pushbuttons provide navigation and
control functions as indicated in Table 4 .6.
Hold down either the Up Arrow or Down Arrow to achieve accelerated scrolling.
Holding down the Up Arrow or Down Arrow navigates one screen at a time for the
first five screens, and then increases to five screens at a time if the button remains
pressed. Accelerated scrolling stops at the newest or oldest SER event record
available, depending on the direction of the scrolling.
When the upper limit of the SER events is reached, press the Down Arrow one
more time and the report will wrap around to display the screen containing the
first SER event. Similarly, when the lower limit of the SER events is reached,
press the Up Arrow one more time and the report will wrap around to display the
screen containing the last SER event.
By default, three SER events are shown per screen. You can change this to five
per screen by setting SER_PP to Y. This will cause the element name and state
information to be shown on the same line, with the element name truncated to ten
characters and the state truncated to eight characters.
Figure 4.20 SER Events Screen
Figure 4.21 No SER Events Screen
Table 4.6 Front-Panel Pushbutton Functions While Viewing SER Events
Pushbutton Description
Up Arrow,
Down Arrow
Navigates one screen at a time up or down. Each screen contains three SER
events. Accelerated scrolling is obtained when the pushbutton remains
pressed (see accelerated scrolling behavior below).
Left Arrow,
Right Arrow
Navigates between SER events to allow adjacent SER events to be displayed
on one screen. For example, if events 1, 2, and 3 are displayed, press the
Right Arrow once to display events 2, 3, and 4 in the same screen. No acceler-
ated scrolling is provided with the Left Arrow and Right Arrow pushbuttons.
ESC Returns to the
Events Menu
ENT Does nothing
Local
Disabled
02/16/06 11:11:01.993
Local
Enabled
02/16/06 10:11:19.090
IN101
Asserted
02/16/06 03:22:01.988
SER Events 001-003
No SER Events
Available
SER Events
