Control
Customizable Screens
Customizable Screens
SEL-400 series relays support custom mimic display screens. Custom mimic dis-
play screens are developed by the SEL factory using your requirements, and then
added to the QuickSet relay driver. The images below show the breaker and
power system variants supported in custom mimic display screens.
Available Circuit Breakers
Figure 5.27 shows the different types of circuit breakers and disconnects available.
Figure 5.26 Interactive Transformer Image Number
Figure 5.27 Different Types of Circuit Breakers and Disconnects
Circuit breaker,
ANSI type,
Closed, vertical
Circuit breaker,
ANSI type,
Open, vertical
Circuit breaker,
ANSI type,
Closed, horizontal
Circuit breaker,
ANSI type,
Open, horizontal
Circuit breaker,
IEC type,
Closed, vertical
Circuit breaker,
IEC type,
Open, vertical
Circuit breaker,
IEC type,
Closed, horizontal
Circuit breaker,
IEC type,
Open, horizontal
Circuit breaker,
Rack type,
Closed, vertical
Circuit breaker,
Rack type,
Open, vertical
Standard Disconnect, open
Standard Disconnect, closed
3-Position Disconnect, open
3-Position Disconnect,
Closed to Ground
3-Position Disconnect,
Closed In-Line
Circuit breaker,
Rack type,
Closed, horizontal
Circuit breaker,
Rack type,
Open, horizontal
