T Roughing tool_55 D1 F 0.35 mm/rev V 400 m/min
3. Enter the following parameters:
Machining Roughing (∇)
Machining direction Longitudinal
Position outside
Machining direction
D 2 inc
Cutting depth
UX 0.4 inc
UZ 0.2 inc
DI 0
Relief cuts Yes
FR 0.200 mm/rev
Set machining area limits No
4. Press the "Accept" softkey.
7. Stock removal (finishing)
1. Press the "Cont. turn." and "Stock removal" softkeys.
The "Stock Removal" input window opens.
2. Enter the following technology parameters:
T Finishing tool_D1 F 0.1 mm/rev V 450 m/min
3. Enter the following parameters:
Machining Finishing (∇∇∇)
Machining direction Longitudinal
Position outside
Machining direction
(from the face to the rear side)
Allowance No
Relief cuts Yes
Set machining area limits No
4. Press the "Accept" softkey.
Creating a ShopTurn program
9.19 Example: Standard machining
Turning
Operating Manual, 06/2019, A5E44903486B AB 333
