Spectracom SecureSync User Manual

1.
Navigate to INTERFACES > REFERENCES: GNSS 0.
Note: Typically, there will be only one GNSS reference, numbered "0".
2.
The GNSS 0 status window will open. To open the configuration window, click Edit in
the bottom-left corner.
OR:
1.
Navigate to INTERFACES > REFERENCES: GNSS Reference.
2.
Click on the INFO button, or the GEAR button to configure the GNSS settings, or review
GNSS reference status information.
Note that the configurable settings displayed in the configuration window are highly
dependent on superordinate settings, as well as receiver manufacturer and type in your
SecureSync unit:
Trimble Resolution-T
®
Trimble Res–SMT GG
®
u-blox M8T
®
.
3.3.3.1 Reviewing the GNSS Reference Status
To view the current status of your GNSS reference:
1.
Navigate to INTERFACES > REFERENCES: GNSS Reference.
2.
Click the INFO button next to GNSS 0. The GNSS 0 status window will display; it con-
tains two tabs, explained in detail below: Main [= default], and Satellite Data.
The "Main" tab
3.3 Managing References
CHAPTER 3 • SecureSync User Reference Guide Rev. 26
183

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
