Table 5-12:
CTCSS exact (1/10 Hz) tones
Code Tone Freq. Code Tone Freq. Code Tone Freq.
XZ 67.0 1B 107.2 6A 173.8
WZ 69.3 2Z 110.9 6B 179.9
XA 71.9 2A 114.8 7Z 186.2
WA 74.4 2B 118.8 7A 192.8
XB 77.0 3Z 123.0 M1 203.5
WB 79.7 3A 127.3 8Z 206.5
YZ 82.5 3B 131.8 M2 210.7
YA 85.4 4Z 136.5 M3 218.1
YB 88.5 4A 141.3 M4 225.7
ZZ 91.5 4B 146.2 9Z 229.1
ZA 94.8 5Z 151.4 M5 233.6
ZB 97.4 5A 156.7 M6 241.8
1Z 100.0 5B 162.2 M7 250.3
1A 103.5 6Z 167.9 0Z 254.1
Table 5-13:
Data Clock Signals
Output Duty Cycle
9.6 kHz, 18.0 kHz, 64.0 kHz 50% ±2%
17 2/3 Hz 888 µs pulse width
26 2/3 Hz 25% low, 75% high
33 1/3 Hz 208 µs pulse width
Table 5-14:
1PPS Duty Cycle
Output Duty Cycle
1PPS 20% ±5%
5.2.4 Telecom Option Cards
This section contains technical information and Web UI procedures relevant to SecureSync
option cards commonly used in the telecommunications industry.
SecureSync User Reference Guide 403
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
