Spectracom SecureSync User Manual

5.4.8 Spectracom Format 3
Format 3 provides a format identifier, time synchronization status character, year, month, day,
time with time zone and DST corrections, time difference from UTC, Standard time/DST indic-
ator, leap second indicator and on-time marker. The Format 3 data structure is shown below:
E x a m p l e m e s s a g e :
FFFFI^YYYYMMDD^HHMMSS±HHMMD L # CR LF
Where:
FFFF Format Identifier (0003)
I Time Sync Status (Space, ?, *)
^ Space separator
YYYY Year (1999, 2000, 2001, etc.)
MM Month Number (01-12)
DD Day of the Month (01-31)
HH Hours (00-23)
MM Minutes (00-59)
SS Seconds (00-60)
± Positive or Negative UTC offset (+,-) Time Difference from UTC
HHMM UTC Time Difference Hours Minutes (00:00-23:00)
D Daylight Saving Time Indicator (S,I,D,O)
L Leap Second Indicator (space, L)
# On time point
CR Carriage Return
LF Line Feed
The time synchronization status character (I) is defined as described below:
? When the receiver is unable to track any satellites and the time synchronization lamp is red.
* When the receiver time is derived from the battery backed clock or set manually through the Setup Port
Interface.
The time difference from UTC, ±HHMM, is selected when the Serial Com or Remote port is con-
figured. A time difference of -0500 represents Eastern Time. UTC is represented by +0000.
SecureSync User Reference Guide 527
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
