Figure 5-58: Model 1204-3E option card rear plate
495
Figure 5-59: Model 1204-0F option card rear plate
495
Figure 5-60: Contact closure relay pinouts
497
Figure 5-61: Model 1204-2E option card rear plate
501
Figure 5-62: Location of jumper switches
501
Figure 5-63: Model 1204-23 option card rear plate
502
Figure 5-64: Model 1204-0B option card rear plate
509
Figure 5-65: Serial port pin-out
512
Figure 5-66: IRIG B time code description
548
Figure 5-67: FAA modified IRIG B
553
Figure 5-68: IRIG E time code description
556
5.11 Document Revision History
Rev ECO Description Date
A 2451 First-generation product manual. May 2010
B 2504 Edits to include software changes implemented in the
latest software version.
August
2010
C 2513 3rd Revision. September
2010
D 2542 Edits to include changes implemented in the latest soft-
ware version. Updated option card information, addi-
tional maintenance.
November
2010
E 2548 Edits to include changes implemented in the latest soft-
ware version. Updated available option module card
information, additional maintenance.
December
2010
F 2643 Edits to include changes implemented in the latest soft-
ware version. Updated option module cards sections,
PTP, SNMP, NTP sections, additional maintenance and
editorial corrections.
April
2011
SecureSync User Reference Guide 575
APPENDIX
