Spectracom SecureSync User Manual

Sanitization
The Delete Position command must also be used when sanitizing a SecureSync unit (ensuring that
no trace of position data remains on the unit). See "Sanitizing the Unit" on page329.
Deleting the GNSS position
To delete the GNSS position:
1.
Disconnect the GNSS antenna from the SecureSync unit (this is required only when san-
itizing the unit).
2.
Navigate to Interfaces > References: GNSS Reference.
3.
Click on the GEAR button next to the GNSS Reference (typically, there is only one ref-
erence, numbered "0"). The GNSS0 window will open:
Locate the Delete Position box, check it, and click Submit.
4.
SecureSync will initiate a GNSS self survey.
Note: In Mobile Receiver Mode it is NOT possible to delete the position and start
the GNSS survey. This feature is only available in Standard Mode and in Single
Satellite Mode. In Single Satellite Mode a GNSS survey may take up to 24 hours.
3.3.3.9 Manually Setting the GNSS Position
Note: This topic applies only to stationary applications, i.e. to Standard mode,
or Single Satellite mode.
The exact geographic position (location and elevation) of the antenna your SecureSync unit—
and thus its onboard GNSS receiver—is a major factor for SecureSync to calculate an accur-
ate System Time from the GNSS reference.
198
CHAPTER 3 • SecureSync User Reference Guide Rev. 26
3.3 Managing References

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
