Spectracom SecureSync User Manual

Command Description
yearget Displays the current year
yearset Used to set the current year
zeroize Applicable to SAASM-equipped SecureSync units only
5.4 Time Code Data Formats
This section describes the different time code data format selections available for use with
SecureSync option cards that accept ASCII data streams as inputs or outputs via their RS-485
and RS-232 interfaces.
Supported are formats like NMEA, BBC, Spectracom, GSSIP, and Endrun.
5.4.1 NMEA GGA Message
The GGA Format provides essential fix data which includes 3D location and accuracy data.
E x a m p l e m e s s a g e :
$GPGGA,123519.00,4807.038,N,01131.000,E,1,08,0.9,545.4,M,46.9,M,,*47
NOTE: The GGA format does not support precision timing and 1PPS functionality; the WebUI
may permit the selection of Message or PPS Pin as PPS Source, but the NMEA GGA Message
will not use either. If this data is required for your application, use the ZDA Message format
instead (see "NMEA ZDA Message" on page520).
Where:
GGA Global Positioning System Fix Data
123519.00 Fix taken at 12:35:19 UTC
4807.038,N Latitude 48 deg 07.038' N
01131.000, E Longitude 11 deg 31.000' E
518 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
