Spectracom SecureSync User Manual

: Colon separator
MM Minutes (00-59)
SS Seconds (00- 60)
D Daylight Saving Time indicator (S,I,D,O)
TZ Time Zone
XX Time Zone offset (00-23)
The leading edge of the first character (CR) marks the on-time point of the data stream.
The time synchronization status character (I) is defined as described below:
? When the receiver is unable to track any satellites and the time synchronization lamp is red.
* When the receiver time is derived from the battery backed clock or set manually through the Setup Port
Interface.
The Daylight Saving Time indicator (D) is defined as:
S During periods of Standard time for the selected DST schedule.
I During the 24-hour period preceding the change into DST.
D During periods of Daylight Saving Time for the selected DST schedule.
O During the 24-hour period preceding the change out of DST.
E x a m p l e :
271 12:45:36 DTZ=08
The example data stream provides the following information:
Sync Status Time synchronized to GNSS
Date Day 271
Time 12:45:36 Pacific Daylight Time
D DST, Time Zone 08 = Pacific Time
5.4.5 Spectracom Format 1
Format 1 converts the received day of year data (001-366) to a date consisting of day of
week, month, and day of the month. Format 1 also contains a time synchronization status char-
acter, year, and time reflecting time zone offset and DST correction when enabled.
SecureSync User Reference Guide 521
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
