Spectracom SecureSync User Manual

Log Tab Name Facility Priority
Alarms Local Use 7 Critical
Oscillator Local Use 7 Debug
GPS Qualification Local Use 7 Warning
Journal Local Use 7 Notice
Update Local Use 7 Information
Timing Local Use 7 Error
System Local Use 7 Emergency
e.
Local Log: Enable or disable this particular log being stored inside SecureSync. When
this box is checked, the log will be stored in SecureSync.
f.
Remote Log: Configure the desired Syslog servers. When this box is checked, the par-
ticular log will be sent to a Syslog server.
In order for the logs to be formatted correctly for Syslog storage, all log entries are displayed
using Syslog formatting. Each log entry contains the date and time of the event, the source of
the log entry, and the log entry itself.
The “time” of all log entries will be in UTC, Local, TAI or GPS time, as configured under
MANAGEMENT > OTHER: Time Management > System Time. For more information, see "Times-
cales" on page149.
4.5.2.7 Setting up a Remote Log Server
Storing log files on a remote log server supports advanced logging functionality.
Adding a remote log server:
1.
Navigate to MANAGEMENT > OTHER: Log Configuration.
2.
In the Remote Log Server panel, click on the PLUS icon in the top-right corner of the panel.
The Add Remote Log Servers window displays.
4.5 Quality Management
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
315

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
