5.
Information about the configurable settings can be found in the corresponding option
card section, see "Option cards listed by their ID number" on page14.
5.2.1.3 Configuring Option Card Inputs/Outputs
The configurable settings of any SecureSync input or output interface are accessible through
the Edit window of the option card to which the input or output belongs. The Edit window can
be accessed in several ways; the procedure below describes the standard way:
1.
Identify the name of the card, (e.g., PPSOUT, 4-BNC), and verify the name of the input
or output you want to configure (e.g., PPS Output 1).
Note: If you have only one input or output of any type, SecureSync will
number that input or output 0. Additional inputs or outputs will be
numbered 1 or above.
2.
Navigate to the INTERFACES > OPTION CARDS drop-down menu, and click the list entry
of the option card identified above. The option card’s Status Summary panel opens:
348 SecureSync User Reference Guide
