Spectracom SecureSync User Manual

b.
Using the supplied cable ties, secure the cable, part number 8195-0000-5000, from the
option card to the white nylon cable tie holders fastened to the mainboard (see
figureabove).
5.2.2.14 [11]: Verifying HW Detection and SW Update
Complete the Option Card installation procedure by verifying that SecureSync detected the
card, and by updating the system software:
a.
Re-install the top cover of the unit chassis (housing), using the saved screws.
Caution: Ensure that screw holes on the card are properly lined up and
secured to the chassis before powering the unit up, otherwise damage to
the equipment may result.
b.
Power on the unit.
c.
Verify the successful installation by ensuring the card has been detected:
SecureSync Web UI, ≤ Version 4.x
Open a web browser, and login to the SecureSync Web UI. Navigate to the STATUS/INPUTS
and/or STATUS/OUTPUTS pages. Information displayed on these pages will vary depending
upon your option module card/SecureSync configuration (for example, the Multi-Gigabit Eth-
ernet option module card has both input and output functionality, and so is displayed in both
pages).
Note: If after an installation the card does not appear to be properly identified, it
may be necessary to update the SecureSync system software to the latest avail-
able version.
SecureSync User Reference Guide 365
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
