Spectracom SecureSync User Manual

5.2.1.2 Viewing Input/Output Configuration Settings
The configurable settings of any SecureSync input or output interface can be viewed in its
Status window. The Status window can be accessed in several ways; the procedure below
describes the standard way:
1.
Identify the name of the option card, (e.g., PPSOUT, 4-BNC) and the name of the input
or output you want to configure (e.g., PPS Output 1).
Note: If you have only one input or output of any type, SecureSync will
number that input or output0. Additional inputs or outputs will be
numbered1 or above.
2.
Navigate to INTERFACES > OPTION CARDS, and click the list entry of the option card
identified above. The option card’s Status Summary panel opens:
3.
Click on the INFO button next to the input or output whose settings you wish to review.
The Status window will open:
4.
If you want to change any of the settings shown in the Status window, click the Edit button
in the bottom-left corner. The Edit window will open:
SecureSync User Reference Guide 347
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
