Spectracom SecureSync User Manual

The incoming input time information may be provided as local time, but System Time may be
configured as UTC time, so internal computations need to be performed. With the Timescale
field set to “Local”, select the name of a previously created Local Clock. The Time Zone and DST
rules, as configured in the Local Clock will be applied to the front panel time display. Refer to
for more information on Local Clocks.
Offset: Provides the ability to account for HAVE QUICK cable delays or other latencies
in the HAVE QUICK outputs. The Offset values are entered in nanoseconds (ns). The avail-
able Offset range is –500 to +500 ms.
5.2.5.6 HAVE QUICK In/Out [1204-29]
The HAVE QUICK input/output option card 1204- 29 provides SecureSync with (1)
HAVEQUICK input and (3) HAVE QUICK outputs.
HAVE QUICK In/Out [1204-29]: Specifications
Inputs/Outputs: (1) HAVE QUICK input/(3) HAVE QUICK outputs
Signal Type and Connector: TTL levels (BNC)
Output Load Impedance: 50Ω
Start of Signal: <10µs after 1PPS output
Programmable phase shift: ±5ns to 500ms with 5ns resolution
Maximum Number of Cards: 6
Ordering Information: 1204-29: HAVE QUICK Input/Output
Figure 5-48: Model 1204-29 option card rear plate
HAVE QUICK Output: Viewing Signal State
To quickly view if a HAVE QUICK Output is enabled or disabled, go to the option card’s Status
Summary panel. For instructions, see: "Viewing an Input/Output Signal State" on page349.
SecureSync User Reference Guide 449
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
