Spectracom SecureSync User Manual

Signature Control: is used to control when the IRIG modulation will be present. This func-
tion allows the modulation to stop under certain conditions;see also "Signature Control"
on page141.
Format: Used to configure the desired IRIG output formatting. The possible values are:
IRIG A
IRIG B
IRIG G
IRIG E
NASA-36
Modulation: Changes the type of output signal modulation. The possible values are:
IRIG DCLS—A TTL-modulated output.
IRIG AM-–An amplitude modulated output. The amplitude of the output is determ-
ined by the value entered in the Amplitude field.
Frequency—The IRIG modulation frequency. This is determined by the con-
figuration of Format and Modulation Type. See also: "IRIG Carrier Frequencies"
on page544.
Coded Expression: Defines the data structure of the IRIG signal, where:
BCD = Binary Coded Decimal
TOY = Time of Year
CF = Control Field
SBS = Straight Binary Seconds
The possible values will vary according to the values of Format and Modulation
Type
Message: The IRIG message of the output.
For IRIG frequency and output specifications, see "IRIG Standards and Specifications" on
page543.
5.2.5.3 STANAG Out [1204-11, -25]
The STANAG Output option card models 1204-11 and 1204-25 provide (2) configurable
STANAG outputs and (1) 1PPS output for the SecureSync platform.
428 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
