Spectracom SecureSync User Manual

SSH: This button takes you to the SSH Setup window. For details on setting up
SSH, see "SSH" on page76.
HTTPS: This button takes you to the HTTPS Setup window. For details on setting up
HTTPS, see "HTTPS" on page65.
System Time Message: Setup a once-per-second time message to be sent to receiv-
ers via multicast. For details, see "System Time Message" on page93.
The Network Services panel is used to enable (ON) and disable (OFF) network services,
as well as the Web UI display mode, details see: "Network Services" on page60.
The Ports panel not only displays STATUS information, but is used also to set up and man-
age SecureSync’s network ports via three buttons:
INFO button: Displays the Ethernet port Status window for review purposes.
GEAR button: Displays the Ethernet port settings window for editing purposes.
TABLE button: Displays a window that allows adding, editing, and reviewing
Static Routes.
2.13.1 General Network Settings
To expedite network setup, SecureSync provides the General Settings window, allowing quick
access to the primary network settings.
To access the General Settings window:
1.
Navigate to MANAGEMENT > Network Setup. In the Actions Panel on the left, click Gen-
eral Settings.
56
CHAPTER 2 • SecureSync User Reference Guide Rev. 26
2.13 Configuring Network Settings

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
