Spectracom SecureSync User Manual

Once you selected a language preference, it will be maintained across logins.
4.5 Quality Management
4.5.1 System Monitoring
4.5.1.1 Status Monitoring via Front Panel
When you have physical access to the SecureSync front panel, the Status LEDs and the Inform-
ation Display allow you to obtain a system status overview.
For more information on the Status LEDs, see "Status LEDs" on page6.
For more information on the Information Display, see "Configuring the Front Panel" on
page269.
It is also possible to display the front panel information display on the Web UI: Navigate to
MANAGEMENT > Front Panel.
4.5.1.2 Status Monitoring via the Web UI
While the SecureSync front panel status LEDs provide an indication of the current operating
status of the system (see "Status Monitoring via Front Panel" above), more detailed status inform-
ation can be accessed via the SecureSync Web UI, such as:
Time synchronization status, including references
GNSS satellites currently being tracked
NTP sync status and current Stratum level
Estimated time errors
Oscillator disciplining
Temperature monitoring
Status of outputs and presence of DC input power.
The HOME screen provides time server status information, while the TOOLS > System Monitor
screen also displays hardware status data, e.g. temperature curves:
276
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
4.5 Quality Management

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
