Spectracom SecureSync User Manual

4.
The NTP Performance Graph panel will appear.
5.
To select the statistics for a particular day, select a date from the drop-down list in the
Select Day for Statistics field. The default date is the present date. Click the Apply button.
To display a higher resolution graph for a shorter time span, move one or both
time sliders at the bottom of the graph inwards.
4.5.1.10 Temperature Management
SecureSync is equipped with one cooling fan, located behind the right-hand side of the front
panel, and several hardware temperature sensors, including:
the board temperature near the CPU
the CPU temperature
the air temperature near the oscillator.
Temperature readings are performed once per minute. The temperature data is logged, and
can be visualized via graphs integrated into the WebUI. The temperature readings can also
be used to control the fan. For details see below under Fan Control Feature.
Units produced before 2016
4.5 Quality Management
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
297

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
